ASTM A213 T22 Tube

Are you Looking for ASTM A213 T22 Tube suppliers in Mumbai? Manufacturer of Alloy Steel T22 Seamless Boiler Tubes in India, check price and dimensions of ASME SA213 T22 Round / Square Tubing.

Alloy Steel

On This Page

Specification Chart of ASTM A213 T22 Tube A213 T22 Composition Mechanical Behaviour of ASME SA 213 Gr T22 Heat exchanger tubes Material Equivalent of SA213 T22 material Outside Diameter Tolerance of T22 Steel Alloy Steel Seamless Tube Wall Thickness Tolerance of A213 Gr T22 seamless tube Alloy Steel T22 Tube Size Chart Weight Chart of ASTM A213 Grade T22 Round Tube

Gallery

ASTM A213 T22 Tube in Detail

Technical Data

Full Specifications

›Technical Data

Specification Chart of ASTM A213 T22 Tube

col_1	col_2
Specifications	ASTM A213 / ASME SA213
Dimensions	ASTM, ASME and API
Length	Double Random, Single Random, & Cut Length.
Outer Diameter	6-2500mm; WT:1-200mm
Schedule	SCH30, SCH40, CH20, STD, SCH80, XS, SCH140, SCH60, SCH80, SCH120, SCH160, XXS
Tubes Size /	1 / 2” OD up to 5” OD, customs diameters also available
Type	EFW / Seamless / Fabricated
Export to	Ukraine, Thailand, Egypt, Oman, Dubai, Korea, Iran, Canada, India, Ireland, Saudi Arabia, Spain, USA,Brazil, Singapore, Indonesia, Peru, etc
Form	Square, Rectangular, Round, Hydraulic Etc
End	Beveled End, Plain End, Treaded

Material Equivalent of SA213 T22 material

col_1	col_2	col_3	col_4
Trade Name	Grade	UNS #	Heater Tubes
2 1/4 Chrome	T22	K21590	A213

Alloy Steel T22 Tube Size Chart

Scroll to see all columns →

NB	Size	OD	40S	5S	10S	S10	S20	S40	S60	XS/80S	S80	S100	S120	S140	S160	XXS
NB	Size	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm
	1/8”	10.29			1.2			1.73			2.41
	1/4”	13.72			1.7			2.24			3.02
	3/8”	17.15			1.7			2.31			3.2
15	1/2”	21.34	2.8	1.7	2.1			2.77		3.73	3.73				4.78	7.47
20	3/4”	26.67	2.9	1.7	2.1			2.87		3.91	3.91				5.56	7.82
25	1”	33.4	3.4	1.7	2.8			3.38		4.55	4.55				6.35	9.09
32	1 1/4”	42.16	3.6	1.7	2.8			3.56		4.85	4.85				6.35	9.7
40	1 1/2”	48.26	3.7	1.7	2.8			3.68		5.08	5.08				7.14	10.2
50	2”	60.33	3.9	1.7	2.8			3.91		5.54	5.54				9.74	11.1
65	2 1/2”	73.03	5.2	2.1	3.1			5.16		7.01	7.01				9.53	14
80	3”	88.9	5.5	2.1	3.1			5.49		7.62	7.62				11.1	15.2
90	3 1/2”	101.6	5.7	2.1	3.1			5.74		8.08	8.08
100	4”	114.3	6	2.1	3.1			6.02		8.56	8.56		11.1		13.5	17.1
125	5”	141.3	6.6	2.8	3.4			6.55		9.53	9.53		12.7		15.9	19.1
150	6”	168.3	7.1	2.8	3.4			7.11		10.97	11		14.3		18.3	22
200	8”	219.1	8.2	2.8	3.8		6.4	8.18	10.3	12.7	12.7	15.1	19.3	20.6	23	22.2
250	10”	273.1	9.3	3.4	4.2		6.4	9.27	12.7	12.7	15.1	19.3	21.4	25.4	28.6	25.4
300	12”	323.9	9.5	4	4.6		6.4	10.3	14.3	12.7	17.5	21.4	25.4	28.6	33.3	25.4
350	14”	355.6	9.5	4	4.8	6.4	7.9	11.1	15.1	12.7	19.1	23.8	27.8	31.8	35.7
400	16”	406.4	9.5	4.2	4.8	6.4	7.9	12.7	16.7	12.7	21.4	26.2	31	36.5	40.5
450	18”	457.2	9.5	4.2	4.8	6.4	7.9	14.3	19.1	12.7	23.8	29.4	34.9	39.7	45.2
500	20”	508	9.5	4.8	5.5	6.4	9.5	15.1	20.6	12.7	26.2	32.5	38.1	44.5	50
550	22”	558.8	9.5	4.8	5.5	6.4	9.5		22.2	12.7	28.6	34.9	41.3	47.6	54
600	24”	609.6	9.5	5.5	6.4	6.4	9.5	17.5	24.6	12.7	31	38.9	46	52.4	59.5
650	26”	660.4	9.5			7.9	13			12.7
700	28”	711.2	9.5			7.9	13			12.7
750	30”	762	9.5	6.4	7.9	7.9	13			12.7
800	32”	812.8	9.5			7.9	13	17.5		12.7
850	34”	863.6	9.5			7.9	13	17.5		12.7
900	36”	914.4	9.5			7.9	13	19.1		12.7

Check Below Countries Where We Supplied

col_1	col_2
ASME SA213 T22 Alloy Steel Seamless Tube for Boiler Superheater Heat-exchanger	Singapore, UAE, Italy, Malaysia
t22 material astm a213 standard alloy tube	Dammam -KSA, UK, Philippines, Poland
Cold drawn seamless T22 alloy steel seamless boiler tube	Europe, United Arab Emirates (UAE), Romania, Norway
ASTM A213 Grade T22 8 Inch Sch 40 Seamless Alloy Steel Tube	Bahrain, Malaysia, Singapore, South Korea
ASTM A213 T22 14" SCH 80 Pipes	Oman, Thailand, Hong Kong, France
ASME SA213 Chrome Moly T22 Tube	Czechia, Malaysia, Thailand, Japan
24 inch Boiler T22 Alloy steel Tube	Qatar, Singapore, Europe, Malaysia
16" SCH XXS ASTM A213 T22 Alloy Steel Tubes	Malaysia, Egypt, Los Alamos -Mexico, Mexico
ASTM A213 T22 3" NB X SCH XXS Tube	Malaysia, China, Bangladesh, Colombia
ASTM A213 T22 cold drawn alloy steel seamless boiler tube	Malaysia, Malaysia, Turkey, Germany
ASME SA213 GR.T22 Seamless Rifled Tube	Philippines, Chile, Canada, Iran
T22 Alloy Steel Seamless Tube for Boiler Superheater	Singapore, United Kingdom -UK, NY 12203 (USA), Malaysia
sch 160 asme sa213 t22 tubing	Ellington -United States, Nigeria, Canada, Australia
High Pressure Steel A213 T22 Tubing	UK, Brazil, Spain, Saudi Arabia (KSA)
T22 5456000 Tube	Dubai, Finland, Malaysia, USA
A213 T22 Seamless tubes used in fluid and oil transmission	Philippines, Belgium, UK, Indonesia
Cold Drawn ASTM A213 T22 Multi-Rifled Seamless steel Boiler Tubes	South Africa, Philippines, Kuwait, Taiwan
ASME SA213 T22 Seamless for Steam Bolier Steel Tube	UAE, Singapore, Europe, South Africa
Thick wall T22 high pressure alloy tube	Sweden, Netherlands, Malaysia, Russia

›Material Properties

A213 T22 Composition

Scroll to see all columns →

C, %	Mn, %	P, %	S, %	Si, %	Cr, %	Mo, %
0.05-0.15	0.30-0.60	0.025 max	0.025 max	0.50 max	1.90-2.60	0.87-1.13

Mechanical Behaviour of ASME SA 213 Gr T22 Heat exchanger tubes

col_1	col_2	col_3	col_4
Tensile Strength , MPa	Yield Strength, MPa	Elongation, %	Hardness, HB
415 min	205 min	30 min	163 max

›Tolerances

Outside Diameter Tolerance of T22 Steel Alloy Steel Seamless Tube

col_1	col_2	col_3
Hot rolled	Outside Diameter, mm	Tolerance, mm
Hot rolled	OD≤101.6	+0.4/-0.8
Hot rolled	101.6＜OD≤190.5	+0.4/-1.2
Hot rolled	190.5＜OD≤228.6	+0.4/-1.6
Cold Drawn	Outside Diameter, mm	Tolerance, mm
Cold Drawn	OD＜25.4	±0.10
Cold Drawn	25.4≤OD≤38.1	±0.15
Cold Drawn	38.1＜OD＜50.8	±0.20
Cold Drawn	50.8≤OD＜63.5	±0.25
Cold Drawn	63.5≤OD＜76.2	±0.30
Cold Drawn	76.2≤OD≤101.6	±0.38
Cold Drawn	101.6＜OD≤190.5	+0.38/-0.64
Cold Drawn	190.5＜OD≤228.6	+0.38/-1.14

Wall Thickness Tolerance of A213 Gr T22 seamless tube

col_1	col_2	col_3
Hot rolled	Outside Diameter, mm	Tolerance, %
Hot rolled	OD≤101.6, WT≤2.4	+40/-0
Hot rolled	OD≤101.6, 2.4＜WT≤3.8	+35/-0
Hot rolled	OD≤101.6, 3.8＜WT≤4.6	+33/-0
Hot rolled	OD≤101.6, WT>4.6	+28/-0
Hot rolled	OD>101.6, 2.4＜WT≤3.8	+35/-0
Hot rolled	OD>101.6, 3.8＜WT≤4.6	+33/-0
Hot rolled	OD>101.6, WT>4.6	+28/-0
Cold Drawn	Outside Diameter, mm	Tolerance, %
Cold Drawn	OD≤38.1	+20/-0
Cold Drawn	OD>38.1	+22/-0

›Dimensions & Weight

Weight Chart of ASTM A213 Grade T22 Round Tube

Scroll to see all columns →

Size NPS	Pipe O.D.	Wall Thickness	Pipe I.D.	Weight per Foot	Standard to XXHY	Schedule / Pipe #	Section Modulus	Gallon Capacity Per Linear Foot
1/2	0.84	0.109	0.622	0.85	STD	40	.0407	.0158
		0.147	0.546	1.09	XHY	80	.0478	.0122
		0.188	0.464	1.31		160	.0528	.0088
		0.294	0.252	1.72	XXHY		.0577	.0026
3/4	1.05	0.113	0.824	1.13	STD	40	.0705	.0277
		0.154	0.742	1.48	XHY	80	.0853	.0225
		0.219	0.612	1.95		160	.1006	.0153
		0.308	0.434	2.44	XXHY		.1103	.0077
1	1.315	0.133	1.049	1.68	STD	40	.1328	.0449
		0.179	0.957	2.17	XHY	80	.1606	.0374
		0.250	0.815	2.85		160	.1904	.0271
		0.358	0.599	3.66	XXHY		.2136	.0146
1 1/4	1.66	0.140	1.380	2.27	STD	40	.2346	.0777
		0.191	1.278	3.00	XHY	80	.2913	.0666
		0.250	1.160	3.77		160	.3421	.0549
		0.382	0.896	5.22			.4110	.0328
1 1/2	1.90	0.145	1.610	2.72	STD	40	.3262	.1058
		0.200	1.500	3.63	XHY	80	.4118	.0918
		0.281	1.338	4.86		160	.5079	.0730
		0.400	1.100	6.41			.5977	.0494
2	2.375	0.109	2.157	2.64		10	.4205	.1898
		0.154	2.067	3.66	STD	40	.5606	.1743
		0.218	1.939	5.03	XHY	80	.7309	.1534
		0.250	1.875	5.68			.8045	.1434
		0.281	1.813	6.29			.8666	.1344
		0.344	1.687	7.47		160	.9806	.1161
		0.436	1.503	9.04	XXHY		1.1043	.0922
2 1/2	2.875	0.120	2.635	3.53		10	.6870	.2833
		0.203	2.469	5.80	STD.	40	1.0640	.2487
		0.216	2.443	6.14			1.1169	.2435
		0.250	2.375	7.02			1.2468	.2301
		0.276	2.323	7.67	XHY	80	1.3386	.2202
		0.375	2.125	10.02		160	1.6371	.1842
		0.552	1.771	13.71	XXXHY		1.9971	.1280
3	3.50	0.120	3.260	4.34			1.0411	.4336
		0.156	3.188	5.58			1.3122	.4147
		0.172	3.156	6.12			1.4265	.4064
		0.188	3.124	6.66			1.5342	.3984
		0.216	3.068	7.58	STD.	40	1.7241	.3840
		0.250	3.000	8.69			1.9372	.3672
		0.281	2.938	9.67			2.1207	.3521
		0.300	2.900	10.26	XHY	80	2.2253	.3431
		0.438	2.624	14.34		160	2.8774	.2811
		0.600	2.300	18.6	XXHY		3.4243	.2158
3 1/2	4.0	0.120	3.760	4.98		10	1.3776	.5768
		0.226	3.548	9.12	STD.	140	2.3939	.5136
		0.250	3.500	10.02			2.6001	.4998
		0.281	3.438	11.17			2.8562	.4821
		0.318	3.364	12.52	XHY	80	3.1400	.4617
		0.636	2..728	22.87	XXHY		4.8795	.3085
4	4.5	0.120	4.260	5.62		10	1.7612	.7404
		0.156	4.188	7.24			2.2354	.7156
		0.188	4.124	8.67			2.6296	.6942
		0.203	4.094	9.32			2.8173	.6838
		0.219	4.062	10.02			3.0184	.6725
		0.237	4.026	10.80	STD.	40	3.2145	.6613
		0.250	4.000	11.36			3.3611	.6528
		0.281	3.938	12.67		60	3.7021	.6326
		0.312	3.876	13.97			4.0273	.6126
		0.337	3.826	15.00	XHY	80	4.2713	.5972
		0.438	3.624	19.02		120	5.1790	.5361
		0.531	3.438	22.53		160	5.8997	.4822
		0.674	3.152	27.57	XXHY		6.7927	.4054
5	5.563	0.188	5.187	10.80			4.1161	1.0979
		0.219	5.125	12.51			4.7279	1.0716
		0.258	5.047	14.63	STD.	40	5.4500	1.0391
		0.281	5.001	15.87			5.8644	1.0204
		0.312	4.939	17.51			6.4074	.99647
		0.344	4.875	19.19			6.9358	.9696
		0.375	4.813	20.80	XHY	80	7.4300	.9449
		0.500	4.563	27.06		120	9.2534	.8495
		0.625	4.313	32.99		160	10.7976	.7590
		0.750	4.063	38.59	XXHY		12.0954	.6734
6	6.625	0.109	6.407	7.59		5	3.5769	1.6748
		0.134	6.357	9.30		10	4.3475	1.6488
		0.156	6.313	10.79			5.0107	1.6260
		0.188	6.249	12.94			5.9351	1.5937
		0.203	6.219	13.94			6.3804	1.5780
		0.219	6.187	15.00			6.8261	1.5620
		0.250	6.125	17.04			7.6905	1.5306
		0.280	6.065	18.99	STD.	40	8.4958	1.5008
		0.312	6.001	21.06			9.3416	1.4688
		0.344	5.937	23.10			10.111	1.4391
		0.375	5.875	25.05			10.893	1.4082
		0.432	5.761	28.60	XHY	80	12.224	1.3541
		0.500	5.625	32.74			13.711	1.2909
		0.562	5.501	36.43		120	14.9806	1.2346
		0.625	5.375	40.09			16.1821	1.1787
		0.719	5.187	45.39		160	17.8243	1.0977
		0.864	4.897	53.21	XXHY		20.025	.9784
		1.000	4.625	60.13			21.7719	.8727
		1.125	4.375	66.14			23.1237	.7809
