API 5L ERW Pipe

Searching for API 5L ERW Pipe suppliers in India? IBR approved manufacturer and exporter of API 5L ERW PSL1/ PSL2 Steel Pipe in Mumbai.

API 5L

On This Page

API 5L ERW Pipe Specification Chart Thickness Chart of Erw Steel Pipe Api 5l API 5L ERW PSL1 pipe Sizes Dimensions of API 5L ERW Pipe API 5L ERW PSL2 Pipes Coating

Gallery

API 5L ERW Pipe in Detail

Technical Data

Full Specifications

›Technical Data

API 5L ERW Pipe Specification Chart

Standard	API 5L
Sizes	Np Size 1/2" to Size 48 " O.D. / WT - Sch 10 to 160, XS, STD, XXS.
Type	ERW
Length	Double Random, Single Random, Any Size upto 12 Meters
End	Screwed, Plain, Bevel, Threaded
Thickness	Schedule 40, 80, 160, XS, XXS
Test Methods	Guided-bend test Hydrostatic test Bend test Flattening test
Export to	Thailand, Singapore, Indonesia, Iran, Spain, Canada, Korea, India, Saudi Arabia, Egypt, Ireland, Brazil, Oman, Dubai, Ukraine, USA, Peru, etc

Thickness Chart of Erw Steel Pipe Api 5l

col_1	col_2
CS 5L wall thickness MM (inch)	Pipes Tolerances MM (inch)
ERW Pipes b	ERW Pipes b
≤ 4,0 ( 0.157)	+ 0,6 (0.024) – 0,5 (0.020)
> 4,0 ( 0.157) to < 25,0 (0.984)	+ 0,150 – 0,125
≥ 25,0 (0.984)	+3,7 (0.146) or + 0,1 t which ever is the greater – 3,0 (0.120) or – 0,1 t whiche ver is the greater

API 5L ERW PSL1 pipe Sizes

Scroll to see all columns →

NPS / (Inches)	Outside Diameter / (Inches)	API 5l ERW Pipes Schedules	API 5l ERW Pipes Schedules_2	API 5l ERW Pipes Schedules_3	API 5l ERW Pipes Schedules_4	API 5l ERW Pipes Schedules_5	API 5l ERW Pipes Schedules_6	API 5l ERW Pipes Schedules_7	API 5l ERW Pipes Schedules_8	API 5l ERW Pipes Schedules_9	API 5l ERW Pipes Schedules_10	API 5l ERW Pipes Schedules_11	API 5l ERW Pipes Schedules_12	API 5l ERW Pipes Schedules_13
NPS / (Inches)	Outside Diameter / (Inches)	Schedule 10	Schedule 20	Schedule 30	Schedule STD	Schedule 40	Schedule 60	Schedule XS	Schedule 80	Schedule 100	Schedule 120	Schedule 140	Schedule 160	Schedule XXS
NPS / (Inches)	Outside Diameter / (Inches)	Wall Thickness (Inches)	Wall Thickness (Inches)	Wall Thickness (Inches)	Wall Thickness (Inches)	Wall Thickness (Inches)	Wall Thickness (Inches)	Wall Thickness (Inches)	Wall Thickness (Inches)	Wall Thickness (Inches)	Wall Thickness (Inches)	Wall Thickness (Inches)	Wall Thickness (Inches)	Wall Thickness (Inches)
1/8	0.405				0.068	0.068		0.095	0.095
1/4	0.540				0.088	0.088		0.119	0.119
3/8	0.675				0.091	0.091		0.126	0.126
1/2	0.840				0.109	0.109		0.147	0.147				0.187	0.294
3/4	1.050				0.113	0.113		0.154	0.154				0.219	0.308
1	1.315				0.133	0.133		0.179	0.179				0.250	0.358
1 1/4	1.660				0.140	0.140		0.191	0.191				0.250	0.382
1 1/2	1.900				0.145	0.145		0.200	0.200				0.281	0.400
2	2.375				0.154	0.154		0.218	0.218				0.344	0.436
2 1/2	2.875				0.203	0.203		0.276	0.276				0.375	0.552
3	3.500				0.216	0.216		0.300	0.300				0.438	0.600
3 1/2	4.000				0.226	0.226		0.318	0.318
4	4.500				0.237	0.237		0.337	0.337		0.438		0.531	0.674
5	5.563				0.258	0.258		0.375	0.375		0.500		0.625	0.750
6	6.625				0.280	0.280		0.432	0.432		0.562		0.719	0.864
8	8.625		0.250	0.277	0.322	0.322	0.406	0.500	0.500	0.594	0.719	0.812	0.906	0.875
10	10.750		0.250	0.307	0.365	0.365	0.500	0.500	0.594	0.719	0.844	1.000	1.125	1.000
12	12.750		0.250	0.330	0.375	0.406	0.562	0.500	0.688	0.844	1.000	1.125	1.312	1.000
14	14.000	0.250	0.312	0.375	0.375	0.438	0.594	0.500	0.750	0.938	1.094	1.250	1.406
16	16.000	0.250	0.312	0.375	0.375	0.500	0.656	0.500	0.844	1.031	1.219	1.438	1.594
18	18.000	0.250	0.312	0.438	0.375	0.562	0.750	0.500	0.938	1.156	1.375	1.562	1.781
20	20.000	0.250	0.375	0.500	0.375	0.594	0.812	0.500	1.031	1.281	1.500	1.750	1.969
22	22.000	0.250	0.375	0.500	0.375		0.875	0.500	1.125	1.375	1.625	1.875	2.125
24	24.000	0.250	0.375	0.562	0.375	0.688	0.969	0.500	1.219	1.531	1.812	2.062	2.344
30	30.000	0.312	0.500	0.625	0.375			0.500
32	32.000	0.312	0.500	0.625	0.375	0.688
34	34.000	0.312	0.500	0.625	0.375	0.688
36	36.000	0.312	0.500	0.625	0.375	0.750
42	42.000		0.500	0.625	0.375	0.750

API 5L ERW PSL2 Pipes Coating

col_1	col_2
Black coated	Coated externally (3PL)
Lined internally	Galvanized
Varnish painted	Anti-rust oil

›Dimensions & Weight

Dimensions of API 5L ERW Pipe

Scroll to see all columns →

NPS (Inches)	Outer diameter	Schedules	Schedules_2	Schedules_3	Wall thickness	Inner diameter	Weight/ft. Inches LBS.
1/8	0.405	10		10S	0.049	0.307	0.18
1/8	0.405	STD	40	40S	0.068	0.269	0.24
1/8	0.405	XS	80	80S	0.095	0.215	0.31
1/4	0.540	10		10S	0.065	0.410	0.32
1/4	0.540	STD	40	40S	0.088	0.364	0.42
1/4	0.540	XS	80	80S	0.119	0.302	0.53
3/8	0.675	10		10S	0.065	0.545	0.42
3/8	0.675	STD	40	40S	0.091	0.493	0.56
3/8	0.675	XS	80	80S	0.126	0.423	0.73
1/2	0.840	5		5S	0.065	0.710	0.53
1/2	0.840	10		10S	0.083	0.674	0.67
1/2	0.840	STD	40	40S	0.109	0.622	0.85
1/2	0.840	XS	80	80S	0.147	0.546	1.08
1/2	0.840	160			0.188	0.464	1.30
3/4	1.050	5		5S	0.065	0.920	0.68
3/4	1.050	10		10S	0.083	0.884	0.85
3/4	1.050	STD	40	40S	0.113	0.824	1.31
3/4	1.050	XS	80	80S	0.154	0.742	1.47
3/4	1.050	160			0.219	0.612	1.94
3/4	1.050	XXH			0.308	0.434	2.44
1	1.315	5		5S	0.065	1.185	0.86
1	1.315	10		10S	0.109	1.097	1.40
1	1.315	STD	40	40S	0.133	1.049	1.67
1	1.315	XH	80	80S	0.179	0.957	2.17
1	1.315	160			0.250	0.815	2.84
1	1.315	XXH			0.358	0.599	3.65
1-1/4	1.660	5		5S	0.065	1.530	1.10
1-1/4	1.660	10		10S	0.109	1.442	1.80
1-1/4	1.660	STD	40	40S	0.140	1.380	2.27
1-1/4	1.660	XS	80	80S	0.191	1.278	2.99
1-1/4	1.660	160			0.250	1.160	3.76
1-1/4	1.660	XXH			0.382	0.896	5.21
1-1/2	1.900	5		5S	0.065	1.770	1.27
1-1/2	1.900	10		10S	0.109	1.682	2.08
1-1/2	1.900	STD	40	40S	0.145	1.610	2.71
1-1/2	1.900	XS	80	80S	0.200	1.500	3.63
1-1/2	1.900	160			0.281	1.388	4.85
1-1/2	1.900	XXH			0.400	1.100	6.40
