ASTM A420 WPL6 Fittings

ASTM A420 WPL6 Fittings

Wide range of ASTM A420 WPL6 Fittings Manufacturer in India. Suppliers LTCS A420 Buttweld Elbow of offers the best price of SA 420 WPL6 Pipe Reducer in Mumbai. View Weight of SA 420 Gr WPL6 Fitting

Carbon Steel

On This Page

Gallery

ASTM A420 WPL6 Fittings in Detail

Technical Data

Full Specifications

›Technical Data

ASTM A420 WPL6 Fittings Specification

SpecificationsASTM A420
sizeSeamless Butt Weld Fittings: 1/2" - 10" / Welded Butt Weld Fittings: 1/2" - 48"
Size Range½" NB to 24" NB in Sch 10s, 40s, 80s, 160s, XXS. (DN6~DN100)
DimensionsASME/ANSI B16.9, ASME B16.28, MSS-SP-43, BS4504, BS4504, BS1560, BS10
Manufacturing processPush, Press, Forge, Cast, etc.
TypeDN15-DN1200
Test CertificatesEN 10204/3.1B / Raw Materials Certificate / 100% Radiography Test Report / Third Party Inspection Report, etc
Origin & MillsJapanese, Indian, USA, Korean, European, Ukraine, Russian
ConnectionWelding
Key markets and industriesBitumen upgraders. Heavy oil refineries. Nuclear power (mostly seamless). Petrochemicals and acids.
ThicknessSCH10, SCH20, SCH30, STD SCH40, SCH60, XS, SCH 80, SCH 100, SCH 120, SCH 140, SCH 160, XXS available with NACE MR 01-75
Bending RadiusR=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom MSS Sp-43
ElbowsAngle : 22.5 deg, 30deg, 45 deg, 90 deg, 180 deg, 1.0D, 1.5D, 2.0D, 2.5D, 3D, 4D, 5D, 6D, 7D-40D . / Standard: ASME B16.9, ASME B16.28, ASME B16.25, MSS SP-75 DIN2605 JISB2311 JISB2312 JISB2313, BS, GB, ISO
Export toSpain, Canada, USA, Iran, Singapore, Indonesia, Dubai, Brazil, Ukraine, Korea, Oman, Ireland, India, Thailand, Egypt, Saudi Arabia, Peru, etc
Specialized manufacturer of90º Elbows, 45º Elbows, Tees, Crosses, Reducers, Pipe Cap, Stub End, Pipe Bend
We provide Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204 3.2, Test Certificates certifying NACE MR0103, NACE MR0175We provide Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204 3.2, Test Certificates certifying NACE MR0103, NACE MR0175

Astm A420 Gr Wpl6 Equivalent

MaterialPipesFttgFlgValvesBolts and Nuts
Carbon Steel / Alloy / / Low-TempA333 Gr 6A420 Gr WPL6A350 Gr LF2A352 Gr LCBA320 Gr L7 / A194 Gr 7
Carbon Steel / Alloy / / Low-TempA333 Gr 3A420 Gr WPL3A350 Gr LF3A352 Gr LC3A320 Gr L7 / A194 Gr 7

A420 Wpl6 Yield Strength

Scroll to see all columns →

col_1col_2col_3col_4col_5col_6col_7col_8col_9
*Temp.-20~100150200250300400500600
*YS35.032.932.131.531.022.928.526.8
*Temp.6507007508008509009501000
*YS25.925.124.223.522.822.121.520.8

ASTM A420 WPL6 Buttweld Pipe Fittings Schedule & Sizes

GRADESCHEDULENOM. PIPE SIZE
WPL6-SSCH 10S1/2″ – 12″
SCH 40S1/2″ – 12″
SCH 80S1/2″ – 12″

Ready Stock of SA420 Grade WPL6 Fitting

col_1col_2
LTCS A420 45 Deg Long Radius ElbowASTM A420 Grade WPL6 End Cap
ASTM A420 WPL6 90 Deg Long Radius ElbowASTM A420 Grade WPL6 Eccentric Reducer
ASTM A420 WPL6 TeeA420 Grade WPL6 Pipe elbow/ bend
ASTM A420 Gr.WPL6 TeeWPL6 Low Temperature Carbon Steel Fittings
LTCS ASTM A420 WPL6 Concentric ReducerLow Temperature Carbon Steel Pipe Bends
ASTM A420 WPL6-S StubendsASTM A420 Gr WPL6 Seamless Pipe Fitting
LTCS ElbowLow Temperature Steel A420 Grade WPL6 Fitting
LTCS Gr WPL6 Buttweld ElbowASTM A420 WPL6 Pipe Cap
ASTM A420 Gr.WPL6 Smls ElbowA420 Gr. WPL6 Reducer
Low Temperature Carbon Steel TeeSMLS Concentric Reducer ASTM A420 WPL6 SCH 40

Know More About Our Clients Worldwide

col_1col_2
a420 wpl6 sch40 30 degree carbon steel elbowsUnited Kingdom -UK, China, Chile, South Africa
Astm Sch40 carbon steel elbow 90 degree a420 wpl6UK, Philippines, United Arab Emirates (UAE), Bahrain
A420 WPL6 90 degree high pressure alloy steel elbowPhilippines, Malaysia, Netherlands, Philippines
ASME B16.9 reducer 10"X6" material ASTM A420/WPL6Europe, Sweden, Egypt, Oman
Elbow 90 Long Radius BW ASTM A420 Gr. WPL6 As per ANSI B16.9Spain, Malaysia, Australia, Germany
A420 WPL6 6inch butt welded pipe fittingsEurope, Singapore, Malaysia, USA
ASME B16.9 ASTM A420 WPL6 90 DEG ElbowCanada, Japan, Italy, Saudi Arabia (KSA)
elbow DN500 BW ASTM A420 WPL6Malaysia, Colombia, Turkey, South Africa
astm a420 wpl6 3 inch sch40 90 pipe elbowMexico, Taiwan, Malaysia, Thailand
ASTM A420 WPL6 8"x SCH160 90 DEGREE LOW-TEMPERATURE STEEL ELBOWMalaysia, South Korea, UK, Bangladesh
astm a420 wpl6 12inch butt welded reducing teePoland, Romania, Singapore, Kuwait
SCH 160 ASME B16.9 BW ASTM A420 WPL6Canada, Malaysia, Iran, Singapore
A420 WPL6 14" Sch80 LR elbowSingapore, Los Alamos -Mexico, Norway, Finland
b16.9 astm a420 wpl6 carbon steel seamless 8 inch bw reducing/equal teeEllington -United States, NY 12203 (USA), Russia, Brazil
ASTM A420 GR WPL6 ansi b16.9 sch40 elbowSingapore, Dammam -KSA, Hong Kong, UAE
Tee ASTM A420 WPL6 6'' SCH40Malaysia, Qatar, Dubai, Nigeria
45 Degree Short Radius Butt Weld Elbow 2inch A420 WPL6Belgium, Czechia, Malaysia, UAE
Concentric Reducer 8IN x 4IN SCH 30 LTCS ASTM A420 WPL6Thailand, Malaysia, UK, Indonesia
ASME B16.9 1/2"-48" ASTM A420 WPL6 45 90 degree elbowMalaysia, Europe, Philippines, France
›Material Properties

A420 Wpl6 Chemical Composition

GradeCMnPSSi
WPL6(1)(2)0.30.60-1.350.0350.040.15-0.30

Astm A420 Wpl6 Mechanical Properties

Tensile Strength (KSI)Yield Strength (KSI)
60-9535
›Dimensions & Weight

Dimensions Chart of WPL6 Fittings

Scroll to see all columns →

col_1col_2col_3col_4col_5col_6col_7col_8col_9col_10col_11col_12col_13col_14col_15
Nom. Pipe SizeASTM A420 WPL6 90° ElbowsASTM A420 WPL6 90° ElbowsASTM A420 WPL6 90° ElbowsASTM A420 WPL6 90° ElbowsASTM A420 WPL6 90° ElbowsASTM A420 WPL6 90° ElbowsASTM A420 WPL6 90° ElbowsASTM A420 WPL6 90° ElbowsASTM A420 WPL6 45° ElbowsASTM A420 WPL6 45° ElbowsASTM A420 WPL6 45° ElbowsASTM A420 WPL6 45° ElbowsASTM A420 WPL6 180° Return Long RadiusASTM A420 WPL6 180° Return Long Radius
Nom. Pipe SizeLong RadiusLong RadiusLong RadiusLong RadiusShort RadiusShort Radius3R3RLong RadiusLong Radius3R3RSTDXS
Nom. Pipe SizeSTDXSSCH. 160XXSSTDXSSTDXSSTDXSSTDXSSTDXS
½.18.25.09.19.35
¾.19.25.09.19.40.65
1.40.50.60.75.250.25.31.751.00
1¼.60.901.001.38.40.38.501.251.75
1½.901.151.801.50.56.75.40.691.882.39
21.602.203.253.501.001.503.004.00.811.191.52.13.234.40
2½3.254.005.137.002.132.806.008.001.752.133.004.006.508.00
35.006.508.5011.03.004.2510.013.02.633.505.007.0010.2513.00
3½6.758.3516.04.506.0013.018.03.504.507.009.0013.0016.75
49.0013.518.020.06.258.5018.025.04.506.109.0013.018.525.0
515.022.032.036.09.6014.029.043.07.5010.715.022.030.044.0
624.535.057.065.018.023.045.070.012.017.523.035.050.070.0
850.071.012011834.047.590.014023.035.045.070.095.0142
1088.010726058.070.015921843.053.080.0109117215
1212516045080.010423331062.084.0117155230320
1416020557210514029840080.0100149200325400
16206276132174390520100135195260412550
18260340167219495660126167248330510690
20320420210275610810160206305405640830
223945207359801972603684907871040
2446060029839287511702383004385858901200
2655072910301370275365515685
3073497513701830367488685915
3610621412197026305317069851315
