Stainless Steel Angle

Are You Looking for Stainless Steel Angle Manufacturers in India? Largest Supplier of SS 304 Unequal Angles in Mumbai. SS 316 Cold Rolled Equal Angles at Best Prices

Stainless Steel

On This Page

Stainless Steel Angle Specification List Chemical Structure of Decorative SS Angle Mechanical Behaviour of Brushed SS Angle Trim Equivalent of Cold Drawn SS Angle 90 Degree Angle Stainless Steel Size Chart Dimensions of Formed Stainless Steel Angle HSN Code of SS Angle

Gallery

Stainless Steel Angle in Detail

Technical Data

Full Specifications

›Technical Data

Stainless Steel Angle Specification List

col_1	col_2
Standard	ASME, ASTM, EN, BS, GB, DIN, JIS, etc
Type	Stuctural Steel Angle, Bars, Equal, Unequal, L, T, Hot Rolled
Size	3/4″ THRU 8″
Export to	Thailand, Egypt, Oman, Dubai, Singapore, Ireland, India, Saudi Arabia, Brazil, Indonesia, Ukraine, Korea, Iran, Spain, Canada, USA, Peru, etc
Thickness	1/8″ thru 5/8″

Equivalent of Cold Drawn SS Angle

Scroll to see all columns →

col_1	col_2	col_3	col_4	col_5	col_6	col_7	col_8
STANDARD	WERKSTOFF NR.	UNS	JIS	BS	GOST	AFNOR	EN
SS 304	1.4301	S30400	SUS 304	304S31	08Х18Н10	Z7CN18‐09	X5CrNi18-10
SS 304L	1.4306 / 1.4307	S30403	SUS 304L	3304S11	03Х18Н11	Z3CN18‐10	X2CrNi18-9 / X2CrNi19-11
SS 304H	1.4301	S30409	–	–	–	–	–
SS 310	1.4841	S31000	SUS 310	310S24	20Ch25N20S2	–	X15CrNi25-20
SS 310S	1.4845	S31008	SUS 310S	310S16	20Ch23N18	–	X8CrNi25-21
SS 310H	–	S31009	–	–	–	–	–
SS 316	1.4401 / 1.4436	S31600	SUS 316	316S31 / 316S33	–	Z7CND17‐11‐02	X5CrNiMo17-12-2 / X3CrNiMo17-13-3
SS 316L	1.4404 / 1.4435	S31603	SUS 316L	316S11 / 316S13	03Ch17N14M3 / 03Ch17N14M2	Z3CND17‐11‐02 / Z3CND18‐14‐03	X2CrNiMo17-12-2 / X2CrNiMo18-14-3
SS 316H	1.4401	S31609	–	–	–	–	–
SS 316Ti	1.4571	S31635	SUS 316Ti	320S31	08Ch17N13M2T	Z6CNDT17‐123	X6CrNiMoTi17-12-2
SS 317	1.4449	S31700	SUS 317	–	–	–	–
SS 317L	1.4438	S31703	SUS 317L	–	–	–	X2CrNiMo18-15-4
SS 321	1.4541	S32100	SUS 321	–	–	–	X6CrNiTi18-10
SS 321H	1.4878	S32109	SUS 321H	–	–	–	X12CrNiTi18-9
SS 347	1.4550	S34700	SUS 347	–	08Ch18N12B	–	X6CrNiNb18-10
SS 347H	1.4961	S34709	SUS 347H	–	–	–	X6CrNiNb18-12
SS 904L	1.4539	N08904	SUS 904L	904S13	STS 317J5L	Z2 NCDU 25-20	X1NiCrMoCu25-20-5

90 Degree Angle Stainless Steel Size Chart

Size in Inches	Est. Weight per Ft. Lbs.	Est. Weight per 20' Bar
3/4 x 3/4 x 1/8	0.59	11.80
1 x 1 x 1/8	0.80	16.00
1 x 1 x 3/16	1.16	23.20
1 x 1 x 1/4	1.49	29.80
1-1/4 x 1-1/4 x 1/8	1.01	20.20
1-1/4 x 1-1/4 x 3/16	1.48	29.60
1-1/4 x 1-1/4 x 1/4	1.92	38.40
1-1/2 x 1-1/2 x 1/8	1.23	24.60
1-1/2 x 1-1/2 x 3/16	1.80	36.00
1-1/2 x 1-1/2 x 1/4	2.34	46.80
2 x 2 x 1/8	1.65	33.00
2 x 2 x 3/16	2.44	48.80
2 x 2 x 1/4	3.19	63.80
2 x 2 x 3/8	4.70	94.00
2-1/2 x 2-1/2 x 3/16	3.07	61.40
2-1/2 x 2-1/2 x 1/4	4.10	82.00
3 x 3 x 1/4	4.90	98.00
4 x 4 x 1/4	6.60	132.00
4 x 4 x 3/8	9.80	196.00

Check Our Reference Material In These Countries

col_1	col_2
hot rolled 304 stainless steel corner angle bar	Philippines, Belgium, Indonesia, Dammam -KSA
ss equal angle steel	Europe, Thailand, France, Qatar
2x2 inch size stainless steel angle bar	Thailand, Malaysia, Germany, Czechia
316L stainless steel angle Iron	Bangladesh, Finland, USA, Malaysia
Hot Rolled 201 304 75x75mm 100x100mm Stainless Steel Angle Bar	Kuwait, Brazil, Saudi Arabia (KSA), South Africa
large stainless steel angle	Singapore, Singapore, South Africa, Bahrain
6# Equal Angle Bars	UK, Nigeria, Australia, Philippines
Hot Rolled 201 Stainless Steel Angle Bars For Building Application	Hong Kong, UAE, Malaysia, Oman
Mirror Finish 416 Unequal Stainless Steel Angle	Iran, Singapore, Italy, Chile
Equal stainless steel angle	Norway, Malaysia, Turkey, United Arab Emirates (UAE)
304 stainless steel Angle	Russia, Dubai, Malaysia, Netherlands
ss304 profile angle	Mexico, UK, Spain, Egypt
50x50x5 Equal Angle 304 Stainless Steel	Malaysia, UAE, Europe, United Kingdom -UK
Stainless Steel Polished Angle straight bar	Poland, Ellington -United States, Canada, UK
stainless steel slotted angle	Canada, Singapore, Malaysia, Philippines
12x100x100mm Unequal Stainless Steel Angle Bar	Romania, Malaysia, Japan, Europe
x12crnis18-9 Stainless Steel Angle Bar	Malaysia, China, Colombia, Sweden
30x30x3mm 304 hot rolled stainless steel angle bar	Los Alamos -Mexico, Philippines, Taiwan, Malaysia
904l stainless steel 45 degree angle	NY 12203 (USA), Malaysia, South Korea, Singapore

›Material Properties

Chemical Structure of Decorative SS Angle

Scroll to see all columns →

Grade	Grade_2	C	Mn	Si	P	S	Cr	Mo	Ni	N	Ti	Fe
304	min.						18.0		8.0
304	max.	0.08	2.0	0.75	0.045	0.030	20.0		10.5	0.10
304L	min.						18.0		8.0
304L	max.	0.030	2.0	0.75	0.045	0.030	20.0		12.0	0.10
304H	min.	0.04					18.0		8.0
304H	max.	0.010	2.0	0.75	0.045	0.030	20.0		10.5
SS 310		0.015 max	2 max	0.015 max	0.020 max	0.015 max	24.00 26.00	0.10 max	19.00 21.00	54.7 min
SS 310S		0.08 max	2 max	1.00 max	0.045 max	0.030 max	24.00 26.00	0.75 max	19.00 21.00	53.095 min
SS 310H		0.04 0.10	2 max	1.00 max	0.045 max	0.030 max	24.00 26.00		19.00 21.00	53.885 min
316	min.						16.0	2.03.0	10.0
316	max.	0.035	2.0	0.75	0.045	0.030	18.0	2.03.0	14.0
316L	min.						16.0	2.03.0	10.0
316L	max.	0.035	2.0	0.75	0.045	0.030	18.0	2.03.0	14.0
316TI		0.08 max	10.00 14.00	2.0 max	0.045 max	0.030 max	16.00 18.00	0.75 max	2.00 3.00
317		0.08 max	2 max	1 max	0.045 max	0.030 max	18.00 20.00	3.00 4.00				57.845 min
SS 317L		0.035 max	2.0 max	1.0 max	0.045 max	0.030 max	18.00 20.00	3.00 4.00	11.00 15.00			57.89 min
SS 321		0.08 max	2.0 max	1.0 max	0.045 max	0.030 max	17.00 19.00		9.00 12.00	0.10 max	5(C+N) 0.70 max
SS 321H		0.04 0.10	2.0 max	1.0 max	0.045 max	0.030 max	17.00 19.00		9.00 12.00	0.10 max	4(C+N) 0.70 max
347/ 347H		0.08 max	2.0 max	1.0 max	0.045 max	0.030 max	17.00 20.00		9.0013.00
410	min.						11.5
410	max.	0.15	1.0	1.00	0.040	0.030	13.5		0.75
446	min.						23.0			0.10
446	max.	0.2	1.5	0.75	0.040	0.030	30.0		0.50	0.25
904L	min.						19.0	4.00	23.00	0.10
904L	max.	0.20	2.00	1.00	0.045	0.035	23.0	5.00	28.00	0.25

Mechanical Behaviour of Brushed SS Angle Trim

col_1	col_2	col_3	col_4	col_5	col_6
Grade	Density	Melting Point	Tensile Strength	Yield Strength (0.2%Offset)	Elongation
304/ 304L	8.0 g/cm3	1400 °C (2550 °F)	Psi 75000 , MPa 515	Psi 30000 , MPa 205	35 %
304H	8.0 g/cm3	1400 °C (2550 °F)	Psi 75000 , MPa 515	Psi 30000 , MPa 205	40 %
310 / 310S / 310H	7.9 g/cm3	1402 °C (2555 °F)	Psi 75000 , MPa 515	Psi 30000 , MPa 205	40 %
306/ 316H	8.0 g/cm3	1400 °C (2550 °F)	Psi 75000 , MPa 515	Psi 30000 , MPa 205	35 %
316L	8.0 g/cm3	1399 °C (2550 °F)	Psi 75000 , MPa 515	Psi 30000 , MPa 205	35 %
317	7.9 g/cm3	1400 °C (2550 °F)	Psi 75000 , MPa 515	Psi 30000 , MPa 205	35 %
321	8.0 g/cm3	1457 °C (2650 °F)	Psi 75000 , MPa 515	Psi 30000 , MPa 205	35 %
347	8.0 g/cm3	1454 °C (2650 °F)	Psi 75000 , MPa 515	Psi 30000 , MPa 205	35 %
904L	7.95 g/cm3	1350 °C (2460 °F)	Psi 71000 , MPa 490	Psi 32000 , MPa 220	35 %

›Dimensions & Weight

Dimensions of Formed Stainless Steel Angle

Sizes (all Dimensions in milimeter)	Approx Weight SS Angle Bar (kilogram/meter)	SS 304 Angle Bar Sizes (all Dimensions in milimeter)	Approx Weight SS 316 Angle Bar (kilogram/meter)
25 x 25 x 3	1.13	63 x 63 x 8	7.50
25 x 25 x 4	1.46	65 x 65 x 4	4.00
25 x 25 x 5	1.78	65 x 65x 5	5.02
30 x 30 x 3	1.37	65 x 65 x 8	7.75
30 x 30 x 4	1.78	70 x 70 x 5	5.35
30 x 30 x 5	2.20	70 x 70 x 6	6.40
40 x 40 x 3	1.83	75 x 75 x 6	6.85
40 x 40 x 4	2.41	75 x 75 x 8	9.05
40 x 40 x 5	2.97	80 x 80 x 6	7.35
50 x 50 x 4	3.05	80 x 80 x 8	9.65
50 x 50 x 5	3.78	80 x 80 x 10	11.98
63 x 63 x 4	3.90	100 x 100 x 8	12.20
63 x 63 x 5	3.90	100 x 100 x 12	18.00

›Standards & Compliance

HSN Code of SS Angle

Hs Code	Description
7222	Other Bars And Rods Of SS; Angles, Shapes And Sections Of SS
72224020	Of Below 80 Mm
72222012	Nickel Chromium Austenitic Type
72223099	Other
7301	Sheet Piling Of Iron , Whether Or Not Drilled, Punched Or Made From Assembled Elements; Welded Angles, Shapes A
73012090	Other
7326	Other Articles Of Iron Or Steels
73269060	Manufactures Of SS
