Stainless Steel Sheet

Stainless Steel Sheet

ISO Approved Stainless Steel Sheet Supplier in India, View Sizes & Dimensions of ASTM A240 Plate/ Shim Stock. Contact Us to Get the Stainless Steel Plate Detailed Price List, Call for Water Jet Cutting.

Stainless Steel

On This Page

Gallery

Stainless Steel Sheet in Detail

Specification

Features & Applications

Stainless Steel Sheet Thickness

  • 0.1 to 5 mm

SS Sheet Width

  • 0.5 to 1 m

Black Stainless Steel Sheet Brand

  • POSCO
  • Jindal Stainless
  • Thyssenkrup
  • TISCO
  • Nippon Metal
  • DKC Korea
  • Outokumpu

Thin Stainless Steel Sheet Length

  • 0.7 to 6 m

ASTM A240 Plate Thickness

  • 2.5 to 100 mm

ASME SA 240 Cold rolled Plate Applications

  • Chemical industries
  • Aerospace
  • Oil & Gas
  • Pharmaceuticals
  • Petrochemicals

Mirror Finish Stainless Steel Sheet Characteristics

  • Fair Machinability
  • Excellent Weldability
  • Non Magnetic
  • Good Forming and Bending
  • Good Corrosion Resistance

Stainless Steel Alloy Plate Width

  • 0.05 to 2 m

SS Plate length

  • 0.1 to 6 m

Stainless Steel Flat Sheet Properties

  • Good corrosion resistance
  • Hygienic properties
  • High strength
  • Excellent finish

Stainless Steel Rolling Sheets Tempers

  • Annealed
  • 1/2 Hard
  • Full Hard
  • 3/4 Hard

SA 240 Clad Plate Tolerances

  • +/- 1/16"

ASME SA 240 Stainless Steel Plate Edge

  • Square
  • Round

Stainless Steel Shim Sheet Dimensional Standard

  • DIN
  • GB
  • ASTM
  • EN
  • JIS
  • SUS

ASTM A240 Stainless Steel Sheet Types

  • Annealed plate
  • Plate
  • Shim sheet
  • Clad plate
  • Foils
  • Rolls

8K Mirror Finish Stainless Steel Sheet Manufacturing methods

  • Cold Rolled
  • Forged
  • Hot Rolled

Classes for Surface Finish of Stainless Steel Diamond Plate

  • A : Finest
  • B: Slightly Less Fine
  • C : Most Basic

Stainless Steel Foil Rolls Welding Method

  • SMAW
  • GTAW
  • SAW
  • GMAW
  • PLASMA

Hot Rolled Stainless Steel Plate Finish

  • Sandblasted
  • Matte
  • Glossy
  • Brushed
  • Mirror
  • Electroless nickel plating

Certification of Cold Rolled Stainless Steel Sheet

  • EN 10204 3.1and 3.2
  • 100% Radiography Test Report
  • Raw Materials Certificate
  • Certificate of Origin legalized
  • Third Party Inspection Report

Stainless Steel Quarto Plate Packaging

  • Steel Strips Bundled
  • Wooden Pallets
  • Customized Pallets
  • Bubble wraps

Austenitic Stainless Steel Cold Rolled Sheet Testing Methods

  • Visual inspection test
  • Nabl approved lab test
  • Flaring Test
  • Non destructive test pmi test
  • Destructive test
  • Chemical test
  • Third party inspection test
  • Mechanical test

Martensitic Stainless Steel Hot Rolled Plate Hardness Type

  • Spring Hard
  • Soft
  • Hard
  • Quarter Hard
  • Half Hard

Bright Annealed Super Austenitic Sheet Cutting Methods

  • Plasma cutting
  • Oxy-propane flame cutting
  • Laser cutting
  • Waterjet cutting

Documentation We Offered for Embossed SS Sheet

  • Copy of Invoice
  • Copy of Packing List
  • MTC
  • Country of Origin

No 8 Mirror Finish SS Sheet ASTM Standard

  • ASTM A240
  • ASME SA240

SS Corrugated Sheet Value Added Services

  • Mechanical Processing
  • Sawing
  • Welding
  • Edge Preparation
  • Blanking
  • Polishing
  • Cutting to Length
  • Slitting
  • Bending
  • Shearing

Technical Data

Full Specifications

›Technical Data

SS Sheet Size Chart

Scroll to see all columns →

Size in inche.125.134.156.187.250.312.375.500.625.750.87511.1251.2501.5001.75022.5003
Size in millimeter3.183.403.964.756.357.929.5312.715.919.122.225.428.631.838.144.550.863.576.2

Flatness Permitted Variations of SS Quarto Plate

Specificed Thck (t), in.Flatness Tolerance for Thck, in.
t < ¼7/16
¼ £ t < 3/83/8
3/8 £ t < ½5/16
½ £ t < ¾5/16
¾ £ t < 15/16
1 £ t < 1½¼
1½ £ t < 4¼
t ³ 4¼

Large Stock Of Stainless Steel Sheet / Plate

col_1col_2
Super Martensitic Stainless Steel Plate Brushed FinishSS Hot Rolled Sheet
Stainless Steel Hot Rolled PlateSuper Martensitic Stainless Steel Plate
Ferritic Stainless Steel Cold Rolled PlateSS Bbq Plate
Austenitic Stainless Steel 10mm PlateStainless Steel Cold Rolled Sheet
Super Martensitic Stainless Steel PlateFerritic Stainless Steel Rolling Plate
Super Martensitic Stainless Steel Plate 2b FinishChromium Stainless Steel Diamond Plate
SS Plate Mill FinishASTM A240 Stainless Steel Thin Plate
Super Martensitic Stainless Steel Custom Cut PlateSS Sheet
Super Martensitic Stainless Steel 1/4 Inch PlateSuper Martensitic Stainless Steel Clad Plate
›Dimensions & Weight

ASTM A240 SS Plate Weight Chart

Thickness in millimeterSize in millimeterSize in millimeter_2Size in millimeter_3Weight in kilogram /meter²
Thickness in millimeter3000 X 15002500 X 12502000 X 1000Weight in kilogram /meter²
.23.21.6
.243.841.92
.284.482.24
.386.083.04
.512.584
.6315.751 .085.04
.882214.087.04
13625168
1.254531.252010
1.55437.52412
272503216
2.59062.54020
2.759968.754422
3108754824
3.2511781.255226
3.512687.55628
3.7513593.756030
41441006432
4.25153106.256834
4.5162112.57236
51801258040
5.5198137.58844
62161509648
6.5234162.510452
725217511256
7.5270187.512060
828820012864

Stainless Steel Plate Metric Dimensions

Thickness (millimeter)Width (millimeter)
.25 to 82032
.4 to 6.351524
.4 to 82032
.25 to 3.51524
.4 to 6.351524
.5 to 41524

Stainless Steel Plate Imperial Dimensions

Width (inches)Gauge (inches)
4813 to 29
4818 to 28
6011 to 24
6012 to 24
7210 to 24
›Finishes & Forms

Finish Types of 18 Gauge ASTM A240 Sheet

Scroll to see all columns →

col_1col_2col_3col_4col_5col_6col_7
2B FinishMirror FinishBrushed FinishEmbossed Finish2R (Bright Annealed) FinishNo.8 – Mirror finishMirror Polished
Patterned FinishHairline FinishNo. 8 FinishNo.4 FinishNo. 4 – Brushed finishNo. 2B – Matte finishPolished Finishes

Polished Stainless Steel Sheet Finish & Sizes

Thickness in millimeterFinishSize in millimeter
.8, 1.0Embossed2500 * 1250
.8, 1.2Rimex Super Mirror2400 * 1200, 2500 * 1250
.9Plain 2B2000 * 1000
.9Bright2000 * 1000
.9, 1.2Brushed Finish2000 * 1000, 2500 * 1250
›Tolerances

ASTM A240 Plate Thickness Tolerance

Specified Thck (t), in.Width, in.Width, in._2Width, in._3Width, in._4
Specified Thck (t), in.w ≤ 144120 < width ≤ 14484 < width ≤ 120w ≤ 84
Specified Thck (t), in.Tolerance Over Specified Thck C,D, in.Tolerance Over Specified Thck C,D, in.Tolerance Over Specified Thck C,D, in.Tolerance Over Specified Thck C,D, in.
t < 3/16.070.055
3/16 £ t < 3/8.085.050.045
3/8 £ t < ¾.090.085.060.055
¾ £ t < 1.100.085.065.060
1 £ t < 2.115.095.075.070
2 £ t < 3.200.175.150.125
3 £ t < 4.225.200.160.150
4 £ t < 6.355.335.200.180
6 £ t < 8.435.355.255.235
8 £ t < 10.550.435.335.315
›Material Properties

Stainless Steel Polished Plate Chemical Formula

Scroll to see all columns →

Grade304304_2304H304H_2304L304L_2310310H310S316316_2316TI316L317L317L_2317321H321904L904L_2410410_2347/ 347H446446_2
GradeMinimumMaximumimumMaximumMinimumMaximumMinimumMaximumMinimumMaximumMinimumMaximumMinimumMaximumMinimumMaximum
Mn222222210142.0222.02.0212.01.5
C.08.04.01.03.015.04 .10.08.035.08.035.035.08.04 .10.08.2.15.08.2
P.045.045.045.020.045.045.045.045.045.045.045.045.045.045.04.045.04
Si.75.75.75.01511.752.01.0.7511.01.0111.0.75
Cr18201820182024262426242616181618161821818217191719192311.513.51722330
S.03.03.03.015.030.030.03.030.030.03.030.030.030.035.03.030.03
Ti4(C+N) .705(C+N) .70
Mo.10.752.03.0.752.03.0343445
N.1.154.753.88553.095.10.10.1.25.1.25
Ni81 .581 .5812192119211921101423101115149129122328.75913.5
Fe57.8957.845

Stainless Steel Rolling Plate Mechanical Characteristics

GradeMelting PointYield Strength (0.2%Offset)Density in g/cm3ElongationTensile Strength
304H2550 °F 1400 °C30000 Psi 205 MPa8.040 %75000 Psi 515 MPa
304/ 304L2550 °F 1400 °C30000 Psi 205 MPa8.035 %75000 Psi 515 MPa
306/ 316H2550 °F 1400 °C30000 Psi 205 MPa8.035 %75000 Psi 515 MPa
310 / 310S / 310H2555 °F 1402 °C30000 Psi 205 MPa7.940 %75000 Psi 515 MPa
3172550 °F 1400 °C30000 Psi 205 MPa7.940 %75000 Psi 515 MPa
316L2550 °F 1399 °C30000 Psi 205 MPa8.040 %75000 Psi 515 MPa
3212650 °F 1457 °C30000 Psi 205 MPa8.040 %75000 Psi 515 MPa
904L2460 °F 1350 °C30000 Psi 205 MPa7.9540 %75000 Psi 515 MPa
3472650 °F 1454 °C30000 Psi 205 MPa8.040 %75000 Psi 515 MPa

Equivalent grades of Stainless Steel Roofing Sheets

Scroll to see all columns →

STANDARDFranceGermanyRussiaBritish StandardEuropeJapanNorth America
STANDARDAFNORWERKSTOFF NR.GOSTBSENJISUNS
304Z7CN18‐091.430108Х18Н10304S31X5CrNi18-10SUS 304S30400
304H1.4301S30409
304LZ3CN18‐101.4306 / 1.430703Х18Н113304S11X2CrNi18-9 / X2CrNi19-11SUS 304LS30403
310S1.484520Ch23N18310S16X8CrNi25-21SUS 310SS31008
3101.484120Ch25N20S2310S24X15CrNi25-20SUS 310S31000
310HS31009
316LZ3CND17‐11‐02 / Z3CND18‐14‐031.4404 / 1.443503Ch17N14M3 / 03Ch17N14M2316S11 / 316S13X2CrNiMo17-12-2 / X2CrNiMo18-14-3SUS 316LS31603
316Z7CND17‐11‐021.4401 / 1.4436316S31 / 316S33X5CrNiMo17-12-2 / X3CrNiMo17-13-3SUS 316S31600
321H1.4878X12CrNiTi18-9SUS 321HS32109
316TiZ6CNDT17‐1231.457108Ch17N13M2T320S31X6CrNiMoTi17-12-2SUS 316TiS31635
316H1.4401S31609
317L1.4438X2CrNiMo18-15-4SUS 317LS31703
3171.4449SUS 317S31700
904LZ2 NCDU 25-201.4539STS 317J5L904S13X1NiCrMoCu25-20-5SUS 904LN08904
347H1.4961X6CrNiNb18-12SUS 347HS34709
3211.4541X6CrNiTi18-10SUS 321S32100
3471.455008Ch18N12BX6CrNiNb18-10SUS 347S34700
›Standards & Compliance

Stainless Steel Sheet HSN Code

HSN CodeProduct Description
7219Flat-rolled products
7219221Universal plates
72192212Nickel chromium austenitic type
72192320Nickel chromium austenitic type
